README.md

SOLIDWORKS Top Ten List 2020

YouTube Video Tutorial: Implementing SOLIDWORKS Top Ten List 2020 from scratch

This examples demonstrates the implementation of 3 features from the SOLIDWORKS Top Ten List 2020

Make Hide/Show Bodies command in toolbar

Adds icon to 'Hide/Show Bodies...' built-in command and places the button into toolbar, menu and command manager

Zoom To Geometry

Zoom to fit command which doesn't consider the reference geometry (planes, axis, sketches) and only zooms to the geometry

Shaft Chamfer

Macro feature to allow creating the shaft chamfer by defining the base radius and angle. Macro feature uses Property Manager page for input and edit of parameters and allows instant preview.
